55-95 SBC Chevy Dual Plane Aluminum Intake Manifold 283 305 327 350 Small Block

Dual Plane Aluminum Intake Manifold

Chevy Small Block, 55-95

This is a new aluminum dual plane intake for small block Chevy. 180° design, big power over a wide RPM range. Ideal for the daily driver and performance street applications, will produce power in the lower RPM range and not kill your bottom end like a single plane would.

These intakes are produced from steel molds to reduce core shift and have all the major features found on the expensive ones! Intake works with 283-400 small blocks up to 1995. Includes special adapter bushings for the middle holes on the '87 to '95 heads. Does not fit the newer Vortec heads. Can be used with either spread bore or square bore style carbs. Provides standard bosses and tapped holes for street accessories such as A/C and alternator brackets. Non EGR.

Features:

• 180° dual plane design for outstanding power from idle to 5500 RPM
• Dual carb pattern, accepts spread bore such as Quadrajets and includes adapter for use with square bore carbs like Holley
• Provision for exhaust heated choke and crossover for street applications
• Ideal port position - allows custom porting for maximum power
• Dual distributor hold-down provisions for extra protection against distributor rotation
• Four corner water outlets
• Accepts late-model water neck, air-conditioning, alternator, and HEI brackets
• Special adapter bushings allows manifold to fit 1987 to 1995 engines
